30 VP-460 - The OSD Menu
Setting Function
Advanced Set:
V Keystone – to set the vertical keystone level E
Useful if the projector is located at an angle above or below the screen. In
the OSD menu the value range shows -80 to 80. This feature is disabled on
interlaced input
Auto Sync Off – to turn the auto sync On/Off.
When ON, 2 minutes after not detecting a valid video signal on the
selected input (or both inputs in the dual window mode), the unit will
disable the syncs and the audio on all the outputs, until a valid input is
again detected or any keypad button is pressed E
When using the VP-460 for audio only, we recommend that
you turn this feature off
Luma Keying – to set the transparency level of the PIP window (see
Section 5.8.1
Volatile parameter; screen may flicker
) E
Pause Set:
Freeze – to ON to freeze the window (freezing the main window will
also mute the audio output) M / P
Blank – to ON to display a blank window (blanking the main window
will also mute the audio output) M / P
Note that any change in the display mode, the input source
and/or the output resolution may cancel the freeze and
blank settings.
Mute – to ON to mute the audio output E
A mute icon appears on screen
Disable Output – to turn the sync and audio On/Off.
When ON, the unit will disable the syncs and mute the audio output
until any keypad button is pressed E
Once Disable Output is enabled, a countdown appears, letting you
cancel the process and revert to the previous state
Test Pattern Set the Test pattern to Slide Bar (non-HDCP), Color Bar (HDCP) or
Off.
Each test pattern includes a sinusoid audio signal at 10dB @1kHz.
We recommend that you set the Display Mode to Single Window (see
Section 5.2 ) and set the Output Resolution to 1080p (see 5.7 Section
Note that the Color Bar test pattern changes the OSD menu coloring and the
following message appears on the display: “Ignore OSD Coloring”
).
Changing the output resolution will not cancel the test
pattern
Factory Reset Reset to factory default values (see Section 9.1
Once Factory Reset is enabled, a countdown appears, letting you cancel the
process and revert to the previous state
) E
