38 VP-460 - Controlling the VP-460
7.2 Controlling via the OSD Menu
You can change PiP Window parameters, main window parameters and entire
system parameters via the OSD menu, as described in
Section 5
7.2.1 Connecting to the VP-460 via RS-232
.
You can connect to the VP-460 via an RS-232 connection using, for example, a PC.
Note that a null-modem adapter/connection is not required.
To connect to the VP-460 via RS-232, Connect the RS-232 9-pin D-sub rear panel
port on the VP-460 unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3,
and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC
