A. Technical data
130 Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH
A.3 Interfaces
A.3.1 I/O interface [X1]
Digital inputs Values
Signal level 18 … 30 V (high active)
Number 14
Reaction time to input 1.6 ms
Reaction time to sample input < 100 μs
Protective function Against polarity reversal
Table A.7 Technical data: Digital inputs
Digital outputs Values
Signal level 24 V (from logic supply)
Output current <= 100 mA
Number 4
Output reaction time < 2 ms
Protective function Polarity reversal, short circuit, inductive load
Table A.8 Technical data: Digital outputs
Analogue inputs Values
Signal level -10 … +10 V
Configuration Differential input
Input reaction time < 250 μs
Protective function Overvoltage to ±30 V
Table A.9 Technical data: Analogue inputs
Analogue outputs Values
Signal level 0 … 10 V
Configuration Single-ended against AGND
Output reaction time < 250 μs
Protective function Short circuit against AGND
Table A.10 Technical data: Analogue outputs
