7. Preparations for commissioning
7.1 General connection instructions
As the routing of the connecting cables is critical for EMC, it is
essential that you read Chapter 6.5.4 EMC-compliant wiring
(Page 115)!
Warning
DANGER!
Failure to follow the instructions in Chapter 2 Safety instructions for
electric drives and controllers (Page 12) can result in material
damage, injury, electric shock, or in extreme cases, even to
fatalities.
7.2 Tools / material
Tools - Slotted head screwdriver
- Phillips screwdriver
- Serial interface cable
- Increment generator cable
- Motor cable
- Power supply cable
- Control cable
7.3 Connecting the motor
Connecting the
motor 1. Insert the motor cable plug in the corresponding socket on the
motor and secure it.
2. Insert the PHOENIX plug into the socket [X6] on the device.
3. Insert the motor cable plug in the corresponding socket on the
motor and secure it.
4. Insert the D-sub plug in socket [X2] of the device and secure the
locking screws.
5. Check all plug connectors once again.
