Page 5

IM-366

when opening the door. Support the weight of the door while lowering,
taking care not to let the door impact any surrounding object or
surface. The door can be removed if necessary.

3.2.1

Disconnect power to the unit prior to opening and performing

any maintenance

3.2.2

Access to the LED modules should be performed by qualified

personnel experienced with solid state lighting only. Contact factory
for support.

3.2.3

Loosen closure screws or disengage latches. Carefully open

electrical housing. See Figure 4.

3.2.4

Surge Protector Replacement

3.2.5

: See Figure 4. Locate the surge

protectors. Disconnect the surge protector via the wiring quick
disconnects. Loosen the clamp band holding the surge protectors in
place. Carefully remove the surge protectors and install the new, AEL
approved surge protectors in the same orientation with the original
screw and wire tie. Re-connect the surge protectors’ quick
disconnects. Perform step 2.3.7.

LED Driver Replacement

3.2.6

: See Figure 4. Before removing

components, disconnect driver input and output leads nearest the
driver via the wiring quick disconnects. Remove the (4) driver screws
to remove the driver from the electrical door; retain screws for reuse.
Install new AEL approved driver and tighten screws securely.
Reconnect all driver input and output leads. Perform step 2.3.7.

Door Replacement:

Loosen closure screws or disengage

latches. Carefully open electrical housing. Disconnect the driver input
and output quick disconnect harnesses and disengage the hinge from
the door via key slot by depressing the spring clip on both sides. See
Figure 4. Replace with new AEL supplied door assembly. Close the
door and secure door closure screws or latches. Tighten evenly and
securely. Perform step 2.3.7.

CAUTION

BE CERTAIN THAT NO WIRING IS PINCHED BETWEEN
THE DOOR AND HOUSING OR BETWEEN THE DOOR AND
REFLECTOR.

5 YEAR LIMITED WARRANTY
