English 5.906-587.0 Rev. 00 (05/14) 47
Vacuum cleaner connection piece Material Part no.
Connection piece IV-vacuum cleaner with
flanged edge for connection of the pipelines
DN80. zinc-coated 6.902-018.0
Connection hose DN80 Description Part no.
Suction hose type "D" made of light PU in DN
80.
For connection of the vacuum cleaner unit to
the pipe system. Suction hose DN80, price per running meter 9.980-724.0
Hose connection pieces for vacuuming points Description Hose Ø Pipe Ø Part no.
Connection piece with flanged edge for the con-
nection of the suction hose with the pipeline.
Initial part with star knob.
End part with slot. End piece DN 52 DN 60 6.902-033.0
End piece DN 72 DN 80 6.902-034.0
Initial part DN 52 DN 60 6.902-035.0
Initial part DN 72 DN 80 6.902-038.0
Threaded connection Material Part no.
Connection piece thread 2" with flanged edge
for DN60 pipe section. stainless steel 6.902-041.0
