44 English 5.906-587.0 Rev. 00 (05/14)
Beam clamps Material ØA B C E Weight
kg Part no.
Beam clamps for fixing pipelines to steel gird-
ers (without welding or drilling).
With adjusting screw M10, D=11 mm and width
B=21 mm. Ø60
zinc-coated 60 50 100 20x1 0,20 6.880-181.0
stainless
steel 60 50 100 20x1 0,20 6.880-182.0
Mounting bracket Material Part no.
Mounting bracket zinc-coated. Load capacity
3.0 kN with 5 mm deformation. zinc-coated 6.880-183.0
Threaded rods Material Description Part no.
Threaded rods 1000 mm long, DIN 975. stainless steel Threaded rod
M10-St37K-A2E DIN 975
7.308-507.0
stainless steel Threaded rod
M10-St37K-A2E DIN 975
7.307-045.0
stainless steel Threaded rod
M12-A2 DIN 975
7.308-508.0
Stock screw Material Description Part no.
stainless steel Stock screw M 10 x 100 mm 6.880-184.0
stainless steel Stock screw M 12 x 100 mm 6.373-331.0
