English 5.906-587.0 Rev. 00 (05/14) 45
Hexagon nuts and washers Material Description Part no.
Hexagon nuts DIN 934 zinc-coated Hexagon nut M10 7.311-006.0
zinc-coated Hexagon nut M12 7.311-008.0
stainless steel Hexagon nut M10 7.311-066.0
stainless steel Hexagon nut M12 7.311-071.0
Washers ISO 7090 zinc-coated Washer 10-200HV-A3E 7.312-005.0
zinc-coated Washer 12-200HV-A3E 7.312-008.0
stainless steel Washer 10-A4 7.312-014.0
stainless steel Washer 12-A2 7.312-054.0
Dowel Material Description Part no.
zinc-coated Impact dowel M10 6.373-229.0
zinc-coated Impact dowel M12 6.373-230.0
synthetic
material Expansion dowel M6 6.373-224.0
synthetic
material Expansion dowel M10 6.373-226.0
synthetic
material Expansion dowel M12 6.373-356.0
Squeezing valve incl. installation material Description Part no.
Squeezing valve 9.983-222.0
Quick ventilator 6.413-217.0
Double adapter 6.395-121.0
Solenoid valve NO 24V= 3/2 6.686-149.0
Screw connection angle 1/4", DN6 6.386-764.0
Connection adapter DN6 6.386-860.0
Hose blue PA 6/4 (by the meter) 6.390-963.0
Angle 6.391-427.0
Screw connection angle 1/8", DN4 6.386-762.0
Cable 3x0.5 with PE 6.642-105.0
Plug PG 7 6.685-987.0
Bushing 6.386-766.0
Sealant with Teflon, 50g 6.286-340.0
