82000-922 D.0

INSTALLATION GUIDE

11

©2009 - 2012 HID Global Corporation. All rights reserved.

Hi-O Networked Controller & Reader

EHR40 AND EHRP40

Glossary

Acronym

Description

Acronym

Description

AC Fail

AC Power Failure Input Sense

GND

Ground

AUX

Auxillary Input or Output

GRN LED

Green LED Output

BATT Fail

Battery Failure Input Sense

GRP SEL

Group Select

CAN_H

Hi-O CANbus High

NC

Normally Closed

CAN_L

Hi-O CANbus Low

NO

Normally Open

CLK

Clock

PIR

Passive Infared device

COM

Common

PoE

Power over Ethernet

Data0

Wiegand Data 0 Input

RED LED

Red LED Output

Data1

Wiegand Data 1 Input

REX

Request-to-Exit Input

Door Mon

Door Monitor Input

RLY

Relay

DS

Door Strike
