Follow the instructions on the web browser screen to configure EDGE EVO.
For EDGE EVO Solo, reference the EDGE EVO Solo User Guide, 83000-902, rev B.x.
Configure
6
Power & Testing
7
Test the system once per year using the web Graphical User Interface
to ensure all wiring and configuration is correct.
For additional installation information, such as PIR (Passive Infared Device) and other active
Request-to-Exit (REX) devices, as well as connecting fire relays, see http://www.hidglobal.com/edgesupport .
Hi-O Interface Modules
Hi-O interface modules are used to interface the EDGE EVO device (Controller / Reader & Module or Networked Controller)
with door electronic components. Components include access control readers, strike, magnetic lock, request to exit, door
position switch, and auxillary devices.
For Hi-O interface module wiring, see their respective Installation Guides.
Go to
www.hidglobal.com > Support > Document Library.
Search the document type as a Installation Guide.
Model Description Part Number
EDM-M EDGE EVO Door Module 82342
EIM-M EDGE EVO Input Module 82340
EWM-M EDGE EVO Reader Module 82360
EDWM-M EDGE EVO Door & Reader Module 82363AM
ELM EDGE EVO Lock Module 82301
EVM Voltage Module 82365
