ROTHENBERGER ROSCOPE 1000 Set TEC 1000 - Manual (Page 4)

2 ENGLISH
Contents Page
1. Safety Notes 4
1.1 Safety Instruction 4
1.2 General Safety Rules 4
2. Technical Data / Specification 6
3 Function of the unit 6
3.1 Description 6
3.2 Standard Equipment 7
3.3 To remove or install the battery pack 7
3.4 Installing the Imager Head Cable 8
3.5 Installing the Camera Accessories 9
3.6 Installing the SD Card 9
3.7 Using an External Monitor 10
3.8 Using the Audio Input 10
3.9 Tool Inspection 10
3.10 Tool and Work Area Set-Up 11
4. Operating Instructions 11
5. Control s 11
6. Icons 12
7. Button Icons 12
8. Menu Icons 13
9. On Screen Navigation 14
9.1 Live Screen 14
9.2 Adjust Imager LED brightness 14
9.3 Zoom 15
9.4 Screen Navigation 15
9.5 Change from Still Image Capture to Video 16
9.6 Capturing an Image 16
9.7 Capturing a Video 16
9.8 Reviewing Saved Files 16
9.9 Deleting Saved Images 17
9.10 Adding and removing an audio tag to an image 17
9.11 Deleting Images and Video 18
9.12 Turn Self Levelling On or Off 18
