ENGLISH

9.11 Deleting Images and Video

Files can be deleted in thumbnail or full screen mode. Refer to “Reviewing Saved Files” – Section

9.8 to enter thumbnail or full screen mode. Select the image or video you would like to delete by

using the

buttons. Press the

button to delete a file. If an audio tag is

present you may delete just the audio by selecting the

icon. Otherwise select

to delete

both Audio Tag (if present) and Image or

to cancel. Once a file is deleted it cannot be

retrieved.

9.12 Turn Self Levelling On or Off

Refer back to section 9.4 for screen navigation architecture, the menu screen necessary to change

this feature is shown in Figure 20 below.

Figure 20 – Up-is-Up Menu Setting

Use the

buttons to change the setting. Press the

button two times to exit into

live mode. You will notice that in the live image, your picture is now rotated “up” with respect to

gravity.

NOTE: You may witness black regions around the perimeter as the live image rotates within the

LCD (see Figure 21). This is a normal result of the format of the imager, zooming in on the

live image will reduce this.

Figure 21 – Up-is-Up OFF / Up-is-Up ON
