Chapter 5: Configuration

ISU 512 User Manual

61202.086L1-1

SETTING DTE OPTIONS

The DTE Options menu is used to select the configuration parameters that con-
trol the operation of the DTE interface ports of the ISU 512, such as the maxi-
mum bit rate and the connector type. Changes to the DTE options affect both
ports (RS-530 and V.35) during dual-port mode and single-port modes of op-
eration.

Maximum Bit Rate

The DTE bit rate can be set for 64K MODE 1 or 56K MODE 1. After selecting
the maximum bit rate (Max Bit Rate), 64K MODE 1 or 56K MODE 1 blinks
to indicate the call type set under network, dial line options. Choosing 64K
MODE 1

changes the call type setting to Data 64kbps. Choosing 56K MODE

changes the call type setting to Data 56kbps. After selecting 64K Mode 1 or

56K Mode 1, options are available for selecting multiples of the call type:

3=CONFIG

2=DTE options

1=Max Bit Rate

1=64K Mode1

1=1x64K

2=2x64K

3=3x64K

4=4x64K

5=5x64K

6=6x64K

7=7x64K

8=8x64K

2=56K Mode1

1=1x56K

2=2x56K

3=3x56K

4=4x56K

5=5x56K

6=6x56K

7=7x56K

8=8x64K
