ADTRAN ISU 512 User Manual
Page 111
Appendix D. Pinouts
61202.086L1-1
ISU 512 User Manual
95
Figure D-5 displays the RS-366 Y cable, part number 1200120L1.
Figure D-5
RS-366 Y Cable
Figure D-6 displays the RS-530 to V.35 adapter cable, part number 1200072L1.
Figure D-6
RS-530 to V.35 Adapter Cable
DB25 Female
Primary RS-366
DB25 Female
Secondary RS-366
DB25 Male
RS-366 Port
DB25 Male
RS-530
V.35
Connector
