61202.086L1-1

ISU 512 User Manual

9

Chapter 3

Installation

INSTALLATION

After unpacking the unit, immediately inspect it for possible shipping dam-
age. If damage is discovered, file a claim immediately with the shipping car-
rier, then contact ADTRAN Customer Service; see the inside back cover of this
manual for phone numbers.

NETWORK CONNECTION

The ISU 512 (U interface) supports either

Dial

or

Leased

operation. The ISU

512 (ST interface) supports only

Dial

operation. Four 8-pin RJ-45 modular

jacks on the rear panel of the ISU 512 allow connection to either network ser-
vice.

Dial

operation uses the ISDN Basic Rate interface and allows the ISU 512 to

dial out over the ISDN network. When used in this mode of operation, the
telephone company provided ISDN Basic Rate interface is connected to the RJ-
45 connectors marked

ISDN IFC #1

,

#2

,

#3

,

and #4

.

Connect the Basic Rate in-

terfaces to the ISU 512 in order, starting with

ISDN IFC #1

, until the maximum

number of lines (four) is reached.

The

Leased

mode of operation supports a dedicated 2B1Q data service at rates

of up to 512 kbps by using nailed up circuits or a permanent connection be-
tween end points. This could be a limited distance modem or point-to-point
connection.

See the appendix

Pinouts

for network connection pin assignments.
