Chapter 5: Configuration
61202.086L1-1 ISU 512 User Manual 31
Figure 5-2
Dial Options Menu
Front Panel
To establish and disconnect calls using the front panel, configure Dial options
for Front Panel. See the section Front Panel for more details.
RS-366
To establish and disconnect calls using the RS-366 parallel dialing port, config-
ure the unit for RS-366 dialing. This enables the RS-366 port on the rear of the
unit. An RS-366 Y cable (part number 1200120L1) is available for dual RS-366
applications such as videoconferencing. DTE RS-366 dialers can end a string
of dialed numbers by sending the end of number (EON) to alert the ISU 512
that the entire number has been sent. Another method is to stop sending num-
bers and allow the ISU to time out, then dial the number. Use the following
options to fine-tune the dialed number termination:
1 sec or EON
The ISU 512 assumes the dial string is fully entered if more than 1 second
elapses since input of the last digit, or the unit receives the EON command.
2 sec or EON
The ISU 512 assumes the dial string is fully entered if more than 2 seconds
elapse since input of the last digit, or the unit receives the EON command.
3=CONFIG
1=Netw. options
2=DTE options
3=BONDING setup
4=Quick setup
1=Dial Line
2=Leased Line
1=Switch type
2=Call type
3=Terminal ID
4=Dial options
5=Auto answer
6=Connect Timout
7=Call Screening
8=Passwords
9=Maint Setup
1=1 sec or EON
2=2 sec or EON
3=5 sec(default)
4=10 sec or EON
5=20 sec or EON
6=Wait for EON
1=Front Panel
2=RS-366
3=V.25
1=HDLC
2=HDLC(FLAGS)
1=enabled
2=disabled
1=RS366 Time
2=Security
0=Call NumID
