NOTICE
All instructions, warranties and other collateral documents are subject to
change at the sole discretion of Horizon Hobby, Inc. For up-to-date product
literature, visit horizonhobby.com and click on the support tab for this product.
Meaning of Special Language
The following terms are used throughout the product literature to indicate
various levels of potential harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of
physical property damage AND a little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of
physical property damage AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability
of property damage, collateral damage, and serious injury OR create a high
probability of superficial injury.
WARNING: Read the ENTIRE instruction manual to become familiar
with the features of the product before operating. Failure to operate the
product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution
and common sense and requires some basic mechanical ability. Failure to
operate this Product in a safe and responsible manner could result in injury
or damage to the product or other property. This product is not intended for
use by children without direct adult supervision. Do not attempt disassembly,
use with incompatible components or augment product in any way without
the approval of Horizon Hobby, Inc. This manual contains instructions for
safety, operation and maintenance. It is essential to read and follow all the
instructions and warnings in the manual, prior to assembly, setup or use, in
order to operate correctly and avoid damage or serious injury.
WARNING AGAINST COUNTERFEIT PRODUCTS
Always purchase from a Horizon Hobby, Inc. authorized dealer to ensure
authentic high-quality Spektrum product. Horizon Hobby, Inc. disclaims all
support and warranty with regards, but not limited to, compatibility and
performance of counterfeit products or products claiming compatibility with
DSM or Spektrum technology.
Age Recommendation: Not for children under
14 years.This is not a toy.
NOTICE: This product is only intended for use with unmanned, hobby-grade,
remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside
of the intended purpose and will not provide warranty service related thereto.
WARRANTY REGISTRATION
Visit www.spektrumrc.com/registration today to register your product.
DSMX ®
Spektrum launched the 2.4GHz RC revolution with its DSM2® technology.
Since then millions of hobbyists the world over have come to embrace 2.4 as
the way to fly. Spektrum leads the way yet again with DSMX—the world’s first
wideband, frequency-agile 2.4GHz signal protocol.
How Does DSMX Work?
It’s a crowded 2.4GHz world out there and every 2.4GHz system faces the
same challenges. DSMX better equips you for these challenges by combining
the superior data capacity and interference resistance of a wideband signal
(like that used in DSM2) with the agility of frequency shifts.
Compared to the wideband signal of DSMX, the narrow band signal of other
frequency hopping 2.4 transmitters is more likely to suffer data loss in the
event of on-channel interference. Think am. It takes more interference to dam a
river than it does a stream.
As more and more 2.4 transmitters vie for the same number of available
channels, there is more interference and more of a risk for data loss. By
adding the agility of frequency shifts to the superior interference resistance of
a wideband signal, DSMX is far less likely to suffer significant data loss from
on-channel interference. The result is quicker connection times and superior
response in even the most crowded 2.4GHz environment.
DSMX Operational Differences
DSMX transmitters and receivers function nearly identically to Spektrum DSM2
systems. Binding, setting the failsafe, recording flight log data, as well as general
use of the system is no different than using any current Spektrum system.
Following are the operational differences:
Brownout Detection - Not Available on DSMX Receivers
DSM2 receivers feature Brownout Detection that flashes the receiver’s LED if
a power interruption occurs. While DSMX receivers have QuickConnect and
recover instantly from a power interruption, the architecture of DSMX prevents
Brownout Detection when operating in DSMX mode.
Flight Log Recording-Fades Higher than DSM2
Note that DSMX moves through the band while DSM2 finds two quiet channels
and remains on those channels. Consequently because DSMX operates on
quiet and noisy channels, it’s common to have more Antenna Fades than when
using DSM2, when used in busy 2.4GHz environments. When taking flight log
data readings, the Frames and Hold Data are important and should be used as
a reference while Fades are insignificant due to the nature of frequency agile
systems. A 10-minute flight will typically result in less than 50 Frame Losses
and no Holds.
Just How Good is DSMX?
In multiple tests, 100 DSMX systems were operated simultaneously for
extended periods of time. During these tests each of the 100 systems was
monitored in flight and on the ground. In every test not a single case of RF link
loss, latency increase or control degradation was experienced or recorded.
