MCR320 Drive
External Installation (Mid- Tower Cases) with MCB120 “Radbox”

Using provided 1- 2” tubing, and routing tubes thru pre-existing case holes
CPU cooling only CPU + (1) Liquid Cooled VGA CPU + (2) Liquid Cooled VGA
 Using optional 3- 8” tubing, and routing tubes thru provided PCI bracket
CPU cooling only CPU + (1) Liquid Cooled VGA CPU + (2) Liquid Cooled VGA
Internal Installation (Full-Tower Cases)

Horizontal, Top of Case
CPU cooling only CPU + (1) Liquid Cooled VGA CPU + (2) Liquid Cooled VGA
EXTREME PERFORMANCE SETUPS - MULTIPLE RADIATORS
Budget 1 - MCR220 Drive + MCR320 QP Budget 2 – MCR320 Drive + MCR220 QP Pump redundancy – MCR320 Drive +
MCR220 Drive
