Steam Requirements
(Steam Heat Option Only)
For machines equipped with optional steam heat,
install piping in accordance with approved commercial
steam practices. Steam requirements are shown in
Table 16.
IMPORTANT: Failure to install the customer
supplied steam filter may void the warranty.
Supply Dispensing
IMPORTANT: Undiluted chemical dripping can
damage the machine. All chemical injection supply
dispenser pumps and dispenser tubing should be
mounted below the washer’s injection point. Loops
do not prevent drips if these instructions are not
followed.
IMPORTANT: Failure to follow these instructions
could damage the machine and void the warranty.
Steam Supply Information
Steam inlet
connection size 40 – 80 pound 1/2 in. (13 mm)
125 pound 3/4 in. (19 mm)
Number of steam inlets 1
Recommended pressure 30 – 80 psi
(2.0 – 5.4 bar)
Maximum pressure 80 psi
(5.4 bar)
Table 16
Hot Surfaces. Will cause severe burns.
Turn steam off and allow steam pipes,
connections and components to cool
before touching.
W505
WARNING
Supply Dispensing
Capacities 20 – 80 125
Number of supply
compartments
4 0 or 5
(optional)
Number of external
liquid supply
connections (OPL only)
5 5
Liquid supply
connection size 3/8 in.
(8 mm)
5/8 in.
(15.9 mm)
Table 17
Dangerous Chemicals. May damage eyes
and skin. Wear eye and hand protection
when handling chemicals; always avoid
direct contact with raw chemicals. Read
the manufacturer’s directions for
accidental contact before handling
chemicals. Ensure an eye-rinse facility
and an emergency shower are within easy
reach. Check at regular intervals for
chemical leaks.
W363
WARNING
