Installation
F8208301 32 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Mounting Bolt Hole Locations (Without Elevated Base Frames)
Figure 15
IMPORTANT: Drawing is not to scale.
CHM2063N
30 Models
23.88 in.
(607 mm)
28
.94
in.
(735
mm)
18.
4
4 in.
(4
68
mm)
2.75 in.
(70 mm)
2.75 in.
(70 mm)
29 in.
(737 mm)
23.5 in.
(597 mm)
37.52 in.
(953 mm)
30.02 in.
(762 mm)
2.56 in.
(65 mm)
2.56 in.
(65 mm)
30
.5 in.
(775
mm)
0.
75
in.
(1
9 m
m
)
Front of Front Panel
Front of Frame
