Introduction
11 F8208301 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
* Denotes Brand
Figure 2
Model Number Familiarization Guide
Sample Model Number: *CN040GC2OU1D01
*C Product Family
N Agency Approval
040 Washer-Extractor Capacity (pounds dry weight of laundry)
G Type of Electrical Control
C Actuation (C = Coin drop)
2 Washer-Extractor Speed Capability (2 = 2 speed)
O Electrical Characteristics
U Panel Type
1 Design Series
D Heat Feature (D = Direct Steam)
01 Option Identification (varies from machine to machine)
CHM2286N
CHM2286N
*CN040GC2OUID01
00000000000
208 – 240
3
Hz Hz Phase Phase
Supply Water: Supply Water: BAR BAR
Number of wires : Number of wires : FLA : FLA : amps amps
3
Circuit Breaker Size : Circuit Breaker Size : amps amps
60 3
Serial No. Serial No.
Model No. Model No.
Voltage Voltage
40
30 - 85 psi, 2 - 5.7
Max. Load : Max. Load :
Schematic : Schematic :
KG KG
18.2
LB LB
EXAMPLE OF NAMEPLATE
