Specifications and Dimensions
17 F8208301 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
V-Speed and F-Speed Models (Continued)
Specification 20 30 40 60 80 125
Cylinder Speeds
Gentle wash/reverse speed, RPM 29 27 26 26 22 26
Wash/reverse speed, RPM 52 52 46 43 40 37
Distribution speed, RPM 92 92 82 77 70 65
Low extract speed, RPM 366 366 328 307 280 260
Medium extract speed, RPM (Not
available on Electronic Control models)
534 534 478 447 408 378
High extract speed, RPM 686 686 613 574 524 485
Centrifugal Force Data
Gentle wash centrifugal force, G 0.25 0.25 0.25 0.25 0.25 0.43
Wash/reverse centrifugal force, G 0.8 0.8 0.8 0.8 0.8 0.8
Distribution centrifugal force, G 2.5 2.5 2.5 2.5 2.5 2.6
Extract Speed 1, G 80 80 80 80 80 80
Extract Speed 2, G 100 100 100 100 100 100
Extract Speed 3 (V-Speed only), G 120 120 120 120 120 120
Extract Speed 4 (V-Speed only), G 140 140 140 140 140 140
Direct Steam Heating (Optional)
Steam inlet connection size, NPT N/A N/A 1/2 1/2 1/2 3/4
Number of steam inlets N/A N/A 1 1 1 1
Steam required to raise bath
water temperature
10
°F (10°C), lbs. (kg)
LOW N/A N/A
2.09
(0.94)
3.6
(1.63)
2.58
(1.17)
3.64
(1.65)
MED N/A N/A
2.40
(1.09)
4.4
(2.00)
4.65
(2.11)
5.17
(2.35)
HIGH N/A N/A
2.84
(1.29)
5.5
(2.50)
5.79
(2.63)
7.78
(3.52)
Average steam use per cycle, bhp (kg) N/A 0.73
(6.9)
1.43
(12.2)
2.32
(15.4)
1.34
(20.9)
1.14
(31.45)
Electrical Heating
Total electrical heating capacity,
kW Input Voltage
200V 5.4 5.4 10.8 10.8 21.7 N/A
240V 7.8 7.8 15.6 15.6 31.2 N/A
380V 6.5 6.5 13.0 13.0 19.6 34.4
415V 7.8 7.8 15.5 15.5 23.3 41
480V 10.4 10.4 15.6 15.6 31.2 54.8
Electrical heating elements 3 3 3 9 12 12
Electrical heat element size, kW 2.6 2.6 5.2 2.6 2.6 4.2
