Installation
33 F8208301 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Mounting Bolt Hole Locations (Without Elevated Base Frames)
Figure 16
IMPORTANT: Drawing is not to scale.
CHM2067N
CHM206
32
.5
in.
(82
6
mm)
20
in.
(5
08
mm
)
23.63 in.
(600 mm)
41.63 in.
(1057 mm)
31.88 in.
(810 mm)
3.5 in.
(89 mm)
36
in
.
(914
mm)
26 in.
(660 mm)
30.63 in.
(778 mm)
0.75 in.
(19 mm)
40 Models
2.32 in.
(59 mm)
0.75 in.
(19 mm)
1.75 in.
(45 mm)
Front of Front Panel
Front of Frame
