Specifications and Dimensions
15 F8208301 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2 Speed Models (Continued)
Specification 20 30 40 60
Direct Steam Heating (Optional)
Steam inlet connection size, NPT N/A N/A 1/2 1/2
Number of steam inlets N/A N/A 1 1
Steam required to raise bath
water temperature,
10 °F (10°C), lbs. (kg)
LOW N/A N/A
2.09
(0.84)
3.6
(0.895)
MED N/A
N/A 2.40
(1.15)
4.4
(1.384)
HIGH N/A
N/A 2.84
(1.48)
5.5
(1.916)
Average steam use per cycle,
bhp (kg)
N/A
0.73
(6.9)
1.43
(12.2)
2.32
(15.4)
Electrical Heating (Optional)
Total electrical heating
capacity, kW
Input Voltage
200V 5.4 5.4 10.8 10.8
240V 7.8 7.8 15.6 15.6
380V 6.5 6.5 13.0 13.0
415V 7.8 7.8 15.5 15.5
480V 10.4 10.4 15.6 15.6
Electrical heating elements 3 3 6 6
Electrical heat element size, kW 2.6 2.6 2.6 2.6
