Installation
Machine Foundation
NOTE: Do not mount on wooden floors, tile floors,
above ground level, or over basements or crawl
spaces because of the high extract speed and the
G-forces exerted.
Thoroughness of detail must be stressed with all
foundation work to ensure a stable unit installation,
eliminating possibilities of excessive vibration during
the extract cycle.
The floor and foundation must be minimum 4000 psi
reinforced concrete set firmly in clean, compacted fill
dirt.
The machine must be anchored to a smooth, level
surface so that the entire base of the machine is
supported and rests on the mounting surface. (Do not
support the machine on only four points.)
Grouting is required.
An elevated foundation must not exceed 8 inches
(203 mm).
Refer to Table 1 for foundation and anchoring
requirements.
Machine Foundation Requirements
Models
Foundation
Thickness
(minimum)
Mounting
Bolt
depth
Installation
Foundation
Method(s)
Anchoring
Method(s)
Requirement*
Anchoring
Bolt
Diameter
Size
(minimum)
2 Speed and F-Speed
(20-60 Models)
4 in.
(102 mm)
2.75 in.
(70 mm)
Direct-to-floor, elevated
base frame, or concrete
foundation
Expansion bolt
or Epoxy bolt
5/8 in.
Variable-Speed
(20-60 Models)
6 in.
(152 mm)
2.75 in.
(70 mm)
Direct-to-floor, elevated
base frame or concrete
foundation
Epoxy bolt 5/8 in.
Variable-
Speed
80 Models
9 in.
(229 mm)
3.25 in.
(83 mm)
Direct-to-floor or
concrete foundation Epoxy bolt or
rebar frame 3/4 in.
125 Models
12 in.
(304 mm)
3.25 in.
(83 mm)
* Recommend SAE 495 Grade 5 or higher strength bolts.
Table 1
To reduce the risk of fire, this appliance
must be bolted to an uncovered concrete
floor.
W731
WARNING
