Installation
F8208301 42 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Before any deviation from specified installation
procedures is attempted, the customer or installer
should contact the distributor.
IMPORTANT: Increasing the drain hose length,
installing elbows, or causing bends will decrease
drain flow rates and increase drain times,
impairing machine performance.
Refer to Table 5 for capacity-specific drain
information.
NOTE: Installation of additional machines will
require larger drain connections. Refer to Table 6.
Drain Information
20 30 40 60 80 125
Drain connection size,
OD
2 in.
(51 mm)
2 in.
(51 mm)
3 in.*
(76 mm)
3 in.*
(76 mm)
3 in.*
(76 mm)
3.5 in.*
(89 mm)
Number of drain outlets 1 1 1 1 1 1
Drain flow capacity 20 gal/min
(76 l/min)
25 gal/min
(95 l/min)
45 gal/min
(170 l/min)
55 gal/min
(208 l/min)
50 gal/min
(189 l/min)
70 gal/min
(265 l/min)
Recommended
drain pit size
1.8 ft.
3
(51 l)
2.5 ft.
3
(71 l)
4.52 ft.
3
(128 l)
4.52 ft.
3
(128 l)
5.9 ft.
3
(167 l)
13 ft.
3
(368 l)
* Also works with 3 in. OD PVC pipe if connected to inside of drain tee connector.
Table 5
Drain Line Sizing
Minimum Drain ID
Model
Number of Machines
1 2 3 4 5
20 2 in. (51 mm) 3 in. (76 mm) 3 in. (76 mm) 4 in. (102 mm) 4 in. (102 mm)
30 2 in. (51 mm) 3 in. (76 mm) 3 in. (76 mm) 4 in. (102 mm) 4 in. (102 mm)
40 3 in. (76 mm) 4 in. (102 mm) 4 in. (102 mm) 4 in. (102 mm) 6 in. (152 mm)
60 3 in. (76 mm) 4 in. (102 mm) 4 in. (102 mm) 4 in. (102 mm) 6 in. (152 mm)
80, 125 4 in. (102 mm) 6 in. (152 mm) 6 in. (152 mm) 8 in. (203 mm) 8 in. (203 mm)
