Mounting Bolt Hole Locations (With Elevated Base Frames)
Figure 22
IMPORTANT: Drawing is not to scale.
CHM2074N
40 Models
23.63 in.
(600 mm)
31.88 in.
(810 mm)
30.88 in.
(784 mm)
2.38 in.
(61 mm)
2.44 in.
(62 mm)
20 in.
(5
08
mm
)
32
.5 in.
(826
mm)
3.62 in.
(92 mm)
26 in.
(660 mm)
41.63 in.
(1057 mm)
36
in.
(9
14 mm)
Front of Front Panel
