Figure 51: connecting to the at-rps2004 unit – Allied Telesis AT-8350GB User Manual
Page 77
AT-8350GB Installation Guide
77
10. Connect the 14-pin molex connector of the RPS cable to the
AT-RPS2004 unit, as displayed in Figure 51.
Figure 51 Connecting to the AT-RPS2004 unit
11. Repeat steps 7 and 8 to connect additional switches to the
AT-RPS2004 unit.
14-pin molex connector
