Product Description
36
❑ Telnet Application Protocol
❑ SNMP management program
RS-232 Terminal Port
One method for accessing the management software is by connecting a
terminal or a PC with a terminal emulation program to the RS-232
Terminal Port on the switch, as indicated in Figure 21. This is commonly
referred to as local or out-of-band management. Please refer to Starting
a Local Management Session on page 78 for instructions on how to
start a local management session.
Figure 21 Local Management
Once the session has been established, the management software’s
Main Menu is displayed on the terminal’s screen, as shown in Figure 15.
Figure 22 AT-S41 Main Menu - Local Management Session
STACK OUT RS232
Terminal Port
AT-8350GB Local Management System
Main Menu
[G]eneral Information
[B]asic Switch Configuration...
[A]dvanced Switch Configuration...
Switch [T]ools...
[S]tatistics
[Q]uit
Command>
Enter the character in square brackets to select option
