Allied Telesis AT-8350GB User Manual
Page 72
Installation
72
3. Facing the back panel of the switch, connect the power supply unit to
the labeled RPS receptacle located on the right side of the switch.
Figure 44 Connecting the AT-RPS2001 Unit to the Switch
4. Tighten the installation screws found on the power supply unit. Make
sure the unit is securely fastened to the back panel of the switch.
Figure 45 Installing the AT-RPS2001 Unit onto the Switch
RPS Receptacle
Installation Screws
RPS Unit
Switch
