Allied Telesis AT-S65 - Manual (Page 88)

Chapter 6: Downloading AT-S65 Management Software Updates
88
Using TFTP to Update the AT-S65 Management Software
If your network uses the TCP/IP protocol, you can use any station on the
network and TFTP software to download a copy of the current AT-S65
management software onto the chassis. The chassis contains the client
portion of the TFTP protocol. The management station you are using must
contain the server portion of the TFTP protocol. Start the TFTP server
before you begin the download procedure.
To download a new software image onto the chassis using TFTP, perform
the following procedure:
1. Establish a local management session on the chassis where you
intend to download the new management software.
2. From the Main Menu, select Administration.
The Administration menu is shown in Figure 13 on page 37.
3. From the Administration menu, select Image Download Through
TFTP and press Enter.
The TFTP Image Download menu is displayed, as shown in Figure 42.
Figure 42. TFTP Image Download Menu
4. Select TFTP Server IP and press Enter.
5. Enter the IP address of the TFTP server.
6. Select Image File Name and press Enter.
7. Enter the file name of the AT-S65 image file stored on the TFTP
server.
8. Select Start TFTP Download.
TFTP Image Download
TFTP Server IP: Null (not configured)
Image File Name: Null (not configured)
Start TFTP Download
Return to Administration Menu ...
