Chapter 2: Basic Parameters
42
Displaying and Naming the Ethernet Port
To display information about the 10/100Base-T Ethernet port and give it a
name, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is shown in Figure 19.
Figure 19. Module Status and Configuration Menu
The MGMT BOARD module reflects the status of the 10/100 Ethernet
port.
2. Select item 9 and press Enter.
Module Status and Configuration Menu
Module -------------WDM Side------------------------------Port Side----------
Status Tx Rx T_SYN R_SYN MaxRate TX Rx SFP
1: Not Present Unknown
2: Not Present Unknown
3: AT-LX3811/2 MISMATCH
4: Not Present Unknown
5: Not Present Unknown
6: Not Present Unknown
7: AT-LX3811/7 On Offline Offline Off Off OM Offline Offline Out
8: Not Present Unknown
9: MGMT BOARD Off
10: AT-RPSA
11: Not Present Unknown
12: AT-CPU FAN1 On
13: AT-CPU FAN2 On
14: AT-CPU FAN
On
Return to Main Menu ...
