AT-S63 Management Software Web Browser Interface User’s Guide
Section I: Basic Operations 81
Note
A 10/100/1000Base-T twisted pair port can operate at 1000 Mbps
only when set to Auto-Negotiation. You cannot manually configure a
10/100/1000Base-T twisted pair port to 1000 Mbps.
MDI/MDIX Crossover
The wiring configuration of a twisted pair port. This setting does not
apply to fiber optic ports. The possible settings are:
Auto - The port automatically configures itself as MDI or MDIX,
depending upon the end node. This is the default. This setting is only
available when a port’s speed and duplex mode are set through Auto-
Negotiation.
MDI - The port uses straight through cable.
MDIX - The port uses a crossover cable.
Ingress Broadcast Filter
Use this parameter to configure a port to forward or discard ingress
broadcast packets. The possible settings are:
Enabled - The port discards ingress broadcast packets.
Disabled - The port forwards ingress broadcast packets. This is the
default setting.
Egress Broadcast Filter
Use this parameter to configure a port to forward or discard broadcast
packets. The possible settings are:
Enabled - The port discards egress broadcast packets.
Disabled - The port forwards egress broadcast packets. This is the
default setting.
For further information about filters, refer to Chapter 6, “Port
Parameters,” in the AT-S63 Management Software Menus Interface
User’s Guide.
Ingress Unknown Unicast Filter
Use this parameter to configure a port to forward or discard ingress
unknown unicast packets. The possible settings are:
Enabled - The port discards ingress unknown unicast packets.
Disabled - The port forwards ingress unknown unicast packets. This is
the default setting.
Egress Unknown Unicast Filter
Use this parameter to configure a port to forward or discard egress
unknown unicast packets. The possible settings are:
