AT-S81 Management Software User’s Guide
Section II: Web Browser Interface 303
6. To configure all of the ports to the same settings, in the All row,
configure one, two, or all of the following settings: STP Status, Priority,
and Path Cost. Click Apply.
Configuring the
Advanced RSTP
Port Settings
To configure the advanced RSTP port settings, perform the following
procedure:
1. From the Basic Config menu, select Rapid Spanning Tree > RSTP
Adv. Port Config.
The RSTP Advanced Port Configuration page opens, as shown in
Figure 93.
Figure 93. RSTP Advanced Port Configuration Page
2. In the Admin/OperEdge column for the port you want to configure,
choose True or False to set whether or not the port will operate as an
edge port.
3. In the Admin/OperPtoP column for the port you want to configure,
choose a setting based on the information in Table 8.
Table 8. RSTP Point-to-Point Status
Admin Operation Port Duplex Operation
Auto True Full
False Half
True True Full or Half
False False Full or Half
