AT-S81 Management Software User’s Guide
Section II: Web Browser Interface 263
Setting Up an LACP Trunk
This section contains the following procedures:
ˆ “Creating an LACP Trunk,” next
ˆ “Configuring the LACP Port Priority” on page 263
ˆ “Viewing the LACP Group Settings” on page 264
ˆ “Disabling an LACP Trunk” on page 265
Note
Create the trunk before you make it an LACP trunk. For more
information, see “Setting Up a Port Trunk” on page 260.
Creating an
LACP Trunk
To create an LACP trunk, perform the following procedure:
1. From the Advanced Config menu, select Trunk Config > Trunk
Config.
The Trunk Configuration page is shown in Figure 77.
2. On the row that corresponds to the trunk you want to enable as an
LACP trunk, from the list, choose one of the following settings:
Active - LACP Active: Ports are in an active negotiation state.
Passive - LACP Passive: Ports are in a passive state where the port
negotiates a bundle by exchanging LACP packets to the peer only if
the far end initiates it.
Note
LACP must be enabled at both ends of the link to be operational.
3. Click Apply.
Configuring the
LACP Port
Priority
LACP port priority determines which port is the backup port to another port
when the link to that port is down. The port with the lowest value has the
highest value, and is selected to join the link aggregation group first.
To configure the LACP port priority, perform the following procedure:
1. From the Advanced Config menu, select Trunk Config > Port Priority
Config.
