AlliedView™-EMS 3.11 Device Manager User’s Guide Page 91 of 130
Status
The status of the control entry.
Owner
The owner (creator) of the control entry.
7.2.3.2 Select Button
: changes the control entry displayed in the Statistics window. To change an entry
displayed, select the entry in the table, then click the Select button. Data collected for the
selected entry is displayed on other tabs thereafter.
Note - When you edit the current entry, or when you add an entry with the same index
number after removing the current entry, make sure to select the entry again. Otherwise,
the changes will not take effect on the other tabs.
7.2.3.3 Add Button
: adds a new entry to the RMON Statistics control table. When you click this button, the
Add Control Table Entry dialog box appears. Enter the Index, the Data Source and the
Owner, then click OK to create an entry.
Add Control Table Entry dialog box
7.2.3.4 Edit Button
: changes the selected entry. To edit the entry, select an entry on the table then click the
Edit button. The Modify Control Table Entry dialog box appears. Change the required
parameters, then click OK. You can also open the dialog box by double-clicking the desired
entry.
