AlliedView™-EMS 3.11 Device Manager User’s Guide Page 39 of 130
Privacy Password
If the Security Level is "Auth / Priv", you need to specify a Privacy Password. Make
sure to set the Privacy Password to be the same as what is configured on the target
device.
Trap Options
Version
This drop down list allows you to select the SNMP trap version to be used in
receiving traps.
Note - Device Manager will only accept "v3" trap version if SNMP version in the
SNMP Options panel is also set to "v3".
Note - Device Manager will only be able to process and display SNMP v3 traps
received from the currently connected device.
Enable 'Trap' operation
To receive traps from a target host's SNMP agent, check this box.
Note - If SNMPc, HP OpenView or Tivoli NetView is running, Device Manager will
not receive any traps. This is because the traps are being intercepted by the
network management application and will never reach Device Manager.
v1/v2c Trap Community Name
Specify the community string that will be used for receiving SNMP v1 or v2c traps.
The default string is "public".
Polling Options
Settings
This button opens the Polling Options dialog box, in which you can change the
polling interval and retry parameters.
Polling Options dialog box
Polling Interval
