AlliedView™-EMS 3.11 Device Manager User’s Guide Page 43 of 130
5.2.3 System Info
Toggles display of system information, namely, System Name, System Location, System
Contact, and System Description.
5.2.4 Threshold
Displays a list of the configured thresholds. You can also create new thresholds or change
the existing thresholds.
The table has the following fields:
• Status - Indicates the status of the MIB variable that Device Manager is monitoring.
• MIB Variable - Name of the MIB variable that Device Manager is monitoring.
• Current Value - Current value of the variable.
• Max Value - Highest value of the variable after Device Manager starts monitoring.
• Min Value - Lowest value of the variable after Device Manager starts monitoring.
• Average Value - Average value of the variable (per second) after Device Manager
starts monitoring.
• Condition - Threshold configured on the variable. If the variable's value exceeds the
threshold, an action is executed. You can configure the type of action to execute in
the User Action tab of the Option menu.
Note - Current, Max, Min and Average values are zero before the first polling. After the first
polling, they all have the same value. Once the threshold is reached, the corresponding row
is highlighted with a red background. Note that thresholds can only be set for MIB variables
of type GAUGE, INTEGER, COUNTER, GAUGE32, INTEGER32, COUNTER32, or
COUNTER64.
Display Threshold
