AlliedView™-EMS 3.11 Device Manager User’s Guide Page 107 of 130
7.3.4.1 History Table
The table shows history data for the selected control table entry. The table has the
following columns:
Max Value
Shows the highest value of each variable after the current history control entry is
selected at the Entry tab.
Min Value
Shows the lowest value of each variable after the current history control entry is
selected at the Entry tab.
Average Value
Shows the average value of each variable after the current history control entry is
selected at the Entry tab.
XXXXXX
Sample Index. A maximum of the 40 latest index numbers are displayed.
7.3.4.2 Sort
To sort table items, click a column title. When you click the column title, table items are
sorted by the column in ascending order. One more click sorts the items in descending
order. To restore the original order, click the Reset Table button.
7.3.4.3 Reset Table Button
: Reorders table items to their original order after sorting.
7.3.5 Plot Chart Tab
In the RMON History Plot Chart tab, RMON history information is displayed in a time-
scaled plotted graph. Data is updated at the polling interval. The horizontal axis holds a
maximum of the 40 latest data values.
Topics:
• Popup Display
