AlliedView™-EMS 3.11 Device Manager User’s Guide Page 104 of 130
7.3.3.1 Available Control Table Entries
This table shows all control table entries configured on the target RMON agent. Data
displayed in the RMON History window is collected using the selected control table entry.
Here you can create a new entry, or modify or remove an existing entry. By default, the
topmost entry is automatically selected.
The Control table is not automatically updated. To see the latest information, click the
Refresh button.
The table has the following columns:
Index
The index number used to identify this entry.
Data Source
The index of the RMON interface which collects history samples for the entry.
Request Buckets
The number of values which you asked the RMON agent to store.
Granted Buckets
The number of values the RMON agent allows you to store.
Sampling Interval
The time interval at which the RMON agent collects data.
Status
The status of the control entry.
Owner
The owner (creator) of the control entry.
7.3.3.2 Select Button
: changes the control entry displayed in the History window. To change the control entry
displayed, select an entry in the table, then click the Select button. Data collected by the
selected entry is displayed on other tabs thereafter.
Note - To display changes to the current entry, or to display a new entry with the same
index number as a previously removed entry, be sure to select the current entry.
Otherwise, the changes will not take effect on the other tabs.
