Chapter 2: Installing the Access Point
42
Figure 19. Rear Panel Upside Down
2. Locate the two screw holes on the rear panel. The holes are used to
secure the top panel to the access point. Refer to Figure 20.
Figure 20. Screws Holes for Securing the Top Panel to the Access Point
3. Lower the top panel over the access point as shown in Figure 21 on
page 43 and secure it by tightening the two retaining screws into the
two corresponding holes on the rear panel of the access point.
Screw Holes
