Chapter 2: Installing the Access Point
40
Attaching the
Bottom Panel to
the Wall or
Ceiling
To attach the bottom panel of the bracket to the wall or ceiling, preform the
following procedure:
Note
Please review “Guidelines” on page 37 before performing this
procedure.
Note
If you are using wall anchors, start with step 1. If you are not using
wall anchors, start with step 4.
1. To install wall anchors, hold the bottom panel at the selected wall or
ceiling location and with a pencil or pen mark the locations of the four
screw holes that are to be used to secure the panel. Refer to
Figure 17.
Figure 17. Marking the Locations of the Bottom Panel Holes on the Wall or
Ceiling
2. If necessary, predrill the holes for the anchors.
3. Install the wall anchors.
