Allied Telesis AT-TQ2450 User Manual
Page 39
AT-TQ2450 Wireless Access Point Installation Guide
39
Figure 15. Screw Holes on the Bottom Panel of the AT-BRKT-J26 Bracket
The holes have a diameter of 4.5 mm (0.2 in.). Refer to Figure 16.
Figure 16. Hole Dimensions
The MAC address of the access point is printed on a label on the
base of the unit. You might want to write the address on a piece of
paper and attach it to the top panel of the bracket after the
installation so that you can easily identify the unit after it is
mounted on the wall or ceiling.
Screw Holes
Screw Holes
4.5 mm
4.5 mm
