AT-GS950/8 Web Interface User Guide
171
Tagged VLAN Port Settings
To configure a VLAN port that is a member of a Tagged VLAN, perform
the following procedure:
1. From the main menu on the left side of the page, select Bridge.
The Bridge folder expands.
2. From the Bridge folder, select VLAN.
The VLAN folder expands.
3. From the VLAN folder, select Port Settings.
The AT-GS950/8 VLAN Port Setting Page is displayed. See Figure 60.
Figure 60. AT-GS950/8 VLAN Port Settings Page
4. For a selected port, set the PVID field to an existing VLAN ID. For an
explanation of the PVID parameter, see “Port VLAN Identifier (PVID)”
on page 162.
5. Set the Acceptable Frame Types to one of the following choices from
the pull-down menu:
All - This selection allows all incoming ingress frames presented to
the port to enter the switch.
Tagged - This selection allows only tagged frames presented to
the port to enter the switch. Untagged frames are discarded at
ingress.
Untagged and Priority Tagged - This selection allows only
untagged frames and frames with a priority tag that are presented
