AT-GS950/8 Web Interface User Guide
133
Note
An error message is generated when you enter a VLAN ID or VLAN
Index which has not been defined, or when you enter a
VLAN ID or VLAN Index without also clicking on the respective radio
button.
4. In the MAC Address field, enter a unicast MAC address.
5. Assign the MAC address a Port Member by selecting the radio button
beside the port number.
Note
You can assign a maximum limit of 256 static unicast addresses on
the switch.
6. Click Apply.
The Static Unicast Address Table is updated and displayed with the
new MAC Address.
See Figure 44 for an example of a Port-based VLAN.
Figure 44. Static Unicast Address Table with Port-Based VLAN Example
7. From the main menu on the left side of the page, select Save Settings
to Flash to permanently save your changes.
