Allied Telesis 8100S Series User Manual
Page 31
Stand-alone Switch Installation Guide for 8100L and 8100S Series Switches
31
Figure 8 shows the back panels of the dual power supply switches.
Figure 8. Back Panels of the Dual Power Supply Switches
AC Power
Connector
AC Power
Connector
(Power Supply 2)
(Power Supply 1)
DC Power
Connector
DC Power
Connector
(Power Supply 2)
(Power Supply 1)
Dual AC Power Supply Models
Dual DC Power Supply Models
