Page 26
Chapter 1: Overview
26
Front Panel
Components
Figure 4 identifies the Fast and Gigabit Ethernet networking ports and the
SFP slots on the 8100S Series switches.
Figure 4. Networking Ports and SFP Slots on the 8100S Series Switches
10/100Base-TX Ports
Combo
Ports and SFP Slots
10/100/1000Base-T
Management
Panel
