107

Appendix A

Technical Specifications

The Technical Specifications for the 8100 Series Standalone Switches are
contained in this section. The specification categories are:

”Physical Specifications” on page 107

”Environmental Specifications” on page 108

”Power Specifications” on page 110

”Certifications” on page 111

”RJ-45 Twisted Pair Port Pinouts” on page 112

”RJ-45 Twisted Pair Port Pinouts” on page 112

”Fiber Optic Port Specifications” on page 113

”RJ-45 Style Serial Console Port Pinouts” on page 115

”Stacking Port Pinouts” on page 116

Note

For the technical specifications for the stacking 8100S Series
switches, refer to the Stacking Switch Installation Guide for 8100S
Series Switches
.

Physical Specifications

Dimensions (H x W x D)

Table 17. Product Dimensions

AT-8100L/8
AT-8100L/8POE
AT-8100L/8POE-E
AT-8100S/24C

4.4 cm x 33.0 cm x 20.3 cm
(1.7 in. x 13.0 in. x 8.1 in.)

AT-8100S/24
AT-8100S/48
AT-8100S/24F-LC
AT-8100S/16F8-SC
AT-8100S/16F8-LC

4.4 cm x 44.1 cm x 29.1 cm
(1.7 in. x 17.3 in. x 11.5 in.)
