Appendix A: Technical Specifications

114

Table 28 lists the specifications of the 100Base-FX fiber optic ports on the
AT-8100S/16F8-LC and AT-8100S/24F-LC Switches.

Table 28. Fiber Optic Port Specifications for the AT-8100S/16F8-LC and

AT-8100S/24F-LC Switches

General

Maximum Distance

2 km

Fiber Optic Cable

50/125 or 62.5/125 µm (core/
cladding) multimode fiber optic
cable

Transmitter

Wavelength

1310 nm

Output optical power with 50/125
µm (core/cladding) multimode
fiber optic cable (BOL)

Minimum: -23.5 dBm
Maximum: -14 dBm

Output optical power with 62.5/125
µm (core/cladding) multimode
fiber optic cable (BOL)

Minimum: -20 dBm
Maximum: -14 dBm

Receiver

Wavelength

1310 nm

Sensitivity

Maximum: -31 dBm

Maximum Input Power

Minimum: -8 dBm
