8 Chapter 1
Right View
Rear View
No. Icon Item Description
1 Kensington lock
slot Connects to a Kensington-compatible computer
security lock.
2 Optical drive Internal optical drive; accepts CDs or DVDs.
3 Optical disk access
indicator Lights up when the optical drive is active.
4 Optical drive eject
button Ejects the optical disk from the drive.
5 Emergency eject
hole Ejects the optical drive tray when the computer is
turned off. Note: Insert a paper clip into the
emergency eject hole to eject the optical drive
tray when the computer is off.
6 USB 2.0 port Connect to USB 2.0 devices (e.g. USB mouse,
USB camera).
7 Modem (RJ-11)
port Connects to a phone line.
No. Icon Item Description
1 Ventilation slots Enable the computer to stay cool, even after
prolonged use.
2 DC-in jack Connects to an AC adapter
